HIGH PURITY PFA TUBE
Application：
-
- Commodity name: HIGH PURITY PFA TUBE
MSK® High Purity PFA Tube is made from high-purity PFA resin through a precise melt extrusion process, ensuring the product possesses excellent physical and chemical properties. Its unique molecular structure provides outstanding corrosion resistance and chemical stability, enabling it to withstand the corrosion of most strong acids, strong bases, and organic solvents.
Key Features
- Chemical Stability: Resistant to corrosion from a wide range of chemicals, making it suitable for high-purity chemical transport.
- High and Low-Temperature Resistance: Maintains stability within a wide temperature range from -196°C to 260°C, suitable for extreme environments.
- Excellent Surface Properties: High lubricity and non-stick properties reduce residue and are easy to clean.
- Outstanding Electrical Insulation: Ideal for high-precision electronics and electrical applications.
- Strong Aging Resistance: UV and oxidation resistant, suitable for long-term use.
MAIN INDICATORS OF THE PRODUCT
- Maximum Operating Temperature: 500 ° F
- Raw materials: AP-230SH,450HP
- Ultrapure grade: AP-231SH,451HP, 951HP or other equivalent raw materials
- Chemically inert to nearly all industrial chemicals and solvents
- Medium: Air, Chemicals, Water, Industrial Gases
MSK® High Purity PFA Tube is committed to providing customers with high-purity, high-performance fluid transport solutions to meet the demands of various critical applications.
Inch Size Outside diameter
(inches)Tube I.D.
(mm)Tube O.D.
(mm)Wall thickness
(mm)1/8" 1.6 3.2 0.8 1/4" 3.95 6.35 1.20 3/8" 6.35 9.53 1.59 1/2" 9.53 12.7 1.59 3/4" 15.88 19.05 1.59 1" 22.20 25.40 1.60 1-1/4" 27.95 31.75 1.90 1-1/2" 33.70 38.10 2.20 2" 45.80 50.80 2.50 Millimeter Size Tube I.D. (mm) Tube O.D.
(mm)Wall thickness
(mm)2 4 1.0 4 6 1.0 6 8 1.0 10 12 1.0 15.8 19 1.6 22 25 1.5 Note: Fittings up to 2 inches can be customized according to different customer requirements
-
Ultra-pure chemical transport systems in semiconductor manufacturing
High-purity fluid management in the pharmaceutical and biotechnology industries
Chemical processing equipment and corrosive fluid handling
Aerospace and precision instrument manufacturing
High-end laboratory and medical equipment
Product Details
Key Features
- Chemical Stability: Resistant to corrosion from a wide range of chemicals, making it suitable for high-purity chemical transport.
- High and Low-Temperature Resistance: Maintains stability within a wide temperature range from -196°C to 260°C, suitable for extreme environments.
- Excellent Surface Properties: High lubricity and non-stick properties reduce residue and are easy to clean.
- Outstanding Electrical Insulation: Ideal for high-precision electronics and electrical applications.
- Strong Aging Resistance: UV and oxidation resistant, suitable for long-term use.
MAIN INDICATORS OF THE PRODUCT
- Maximum Operating Temperature: 500 ° F
- Raw materials: AP-230SH,450HP
- Ultrapure grade: AP-231SH,451HP, 951HP or other equivalent raw materials
- Chemically inert to nearly all industrial chemicals and solvents
- Medium: Air, Chemicals, Water, Industrial Gases
MSK® High Purity PFA Tube is committed to providing customers with high-purity, high-performance fluid transport solutions to meet the demands of various critical applications.
| Inch Size | |||
| Outside diameter (inches) |
Tube I.D. (mm) |
Tube O.D. (mm) |
Wall thickness (mm) |
| 1/8" | 1.6 | 3.2 | 0.8 |
| 1/4" | 3.95 | 6.35 | 1.20 |
| 3/8" | 6.35 | 9.53 | 1.59 |
| 1/2" | 9.53 | 12.7 | 1.59 |
| 3/4" | 15.88 | 19.05 | 1.59 |
| 1" | 22.20 | 25.40 | 1.60 |
| 1-1/4" | 27.95 | 31.75 | 1.90 |
| 1-1/2" | 33.70 | 38.10 | 2.20 |
| 2" | 45.80 | 50.80 | 2.50 |
| Millimeter Size | ||
| Tube I.D. (mm) | Tube O.D. (mm) |
Wall thickness (mm) |
| 2 | 4 | 1.0 |
| 4 | 6 | 1.0 |
| 6 | 8 | 1.0 |
| 10 | 12 | 1.0 |
| 15.8 | 19 | 1.6 |
| 22 | 25 | 1.5 |
Note: Fittings up to 2 inches can be customized according to different customer requirements
